The Importance of Fire Resistant Duct Seals for Building and Industrial Safety
Fire Resistant Duct Seals are essential in ensuring that cables and other services passing through walls, floors and ceilings are protected against the spread of fire. As the demand for more robust fire protection systems increases, understanding the materials, standards and techniques involved in fire stopping is crucial. This guide will walk you through everything you need to know about Fire Resistant Duct Sealants – from key products like DuctSeal FR to the various standards (e.g. BS EN 1366-3) and materials like Fire Rated Intumescent Foam that ensure safety.
What are Fire Resistant Duct Seals?
Duct Sealing is only considered fire resistant when its materials can prevent the passage of smoke, fire and gases through service penetrations, such as ducts, cables, or pipes, in the event of a fire. Effective fire stopping helps to compartmentalise the building. This reduces the spread of fire and gives occupants more time to evacuate. It also allows firefighters to control the blaze more effectively.
Key Fire Protection Standards
One of the most critical aspects of Fire Resistant Duct Sealing is ensuring that the products you use are tested to meet industry standards. Some of the most recognised standards include:
- BS EN 1366-3:2021: This standard outlines the testing and performance requirements for fire resistance in service installations, such as ducts and cables. Products tested to this standard offer up to 4 hours of fire resistance, providing essential protection in the event of a fire.
- UL 1479: In the United States, this standard actively evaluates the fire-resistance performance of penetration firestop systems and helps assess duct sealing materials.
These standards ensure that the materials used in duct sealing can withstand high temperatures and prevent the spread of fire and smoke for a specified period. This is typically 1-4 hours, depending on the rating of the system.
A Short Glossary of Materials Used for Fire Resistant Duct Seals
When exploring the world of Fire Resistant Duct Seals, you’re likely to come across a range of specialist terms. To help demystify the jargon, we’ve quickly broken down some of the most commonly heard materials and technologies used in modern fire stopping systems:
Polyurethane Foam
Polyurethane Foam is one of the most widely used sealing materials. It is often used in combination with other materials like Intumescent Sealants to provide enhanced protection. Called PU Foam for short, this can expand when exposed to heat. This effectively seals any gaps or cracks in ducts and around cables.
Intumescent Sealants
Intumescent Sealants are another popular choice for Fire Resistant Duct Seals. These sealants expand when exposed to high temperatures. They form a thick, insulating barrier that prevents the spread of flames and smoke. This technology is essential for creating a secure seal in areas that experience high temperatures during a fire.
Fire Rated Expanding Foam
For larger gaps and penetrations, Fire Rated Expanding Foam is often used. Fire Rated Foam is highly effective at filling large spaces and hard-to-reach areas, providing an additional layer of protection. This fire rated foam resists fire and works well in areas that require a more substantial barrier.
Expandable Graphite
In certain applications, especially where resistance to high heat and gases is required, Expandable Graphite is a popular choice. Graphite expands when exposed to heat, helping to seal penetrations and prevent the passage of flames and smoke.
DuctSeal FR: A Trusted Solution for Fire Resistant Duct Sealing
One of the most trusted solutions on the market today is DuctSeal FR – developed by AC Cable Solutions and proudly distributed in the UK by E-Tech Components as an authorised partner. This advanced sealing system has been gaining significant traction among utility companies both in the UK and internationally. Especially in high-risk environments such as electricity substations. Ultimately, DuctSeal FR provides the critical fire protection needed for Medium Voltage (11kV/33kV) and High Voltage (66kV/132kV) cables as they pass through ducts and enter buildings.
Why Choose DuctSeal FR for Fire Resistant Duct Sealing?
DuctSeal FR offers superior fire resistance, making it an ideal choice for installations where safety and operational integrity are paramount. Here’s why it’s becoming a go-to solution for many industries:
- Fire Resistance: DuctSeal FR can withstand temperatures for up to 4 hours, as tested according to the BS EN 1366-3:2021 standard. This ensures the product not only holds up under extreme conditions but also maintains its structural integrity during a fire. The ability to provide reliable protection for up to 240 minutes is essential in high-risk environments. In settings like substations, every second counts.
- Intumescent Technology: At the core of DuctSeal FR is its use of Intumescent Sealant, which allows the material to expand when exposed to heat, effectively sealing any gaps and preventing the spread of fire and smoke. This makes it particularly effective in preventing fire from traveling along cable ducts or through structural penetrations.
- A Water, Gas and Fire Tight Seal: Not only does DuctSeal FR offer robust fire protection, but it also acts as a barrier against water ingress and the spread of flammable gases. This dual protection plays a crucial role in preventing flooding and reducing the risk of toxic gas exposure. Especially in high-risk environments like substations where both fire and water damage pose serious threats.
- Low Smoke Zero Halogen: Safety extends beyond fire protection with DuctSeal FR. The product produces minimal smoke and contains zero halogens, significantly reducing the risk of toxic fumes during a fire – an essential feature in confined spaces such as substations or industrial settings.
Key Features of DuctSeal FR
- Fire resistant for up to 4 hours (tested to BS EN 1366-3:2021)
- MEKO-free, Fybrid, Non-Hazardous Intumescent Sealant and sleeve technology for reliable fire stopping
- One-of-a-kind patented Trefoil/Triplex Cable Separation
- Resists toxic gases, hydrocarbons and microbial growth
- Compliant with multiple industry standards: DSEAR, WIMES, DCG, APEA, BLUEBOOK, ATEX
- Easy installation with maintenance-friendly design
A Comprehensive Solution for Substations and High-Risk Environments
AC Cable Solutions engineered DuctSeal FR to provide reliable fire stopping in high-risk industrial environments, particularly for utility companies managing High and Medium Voltage Cables. Its unique blend of Intumescent Technology, fire resistance and versatility make it the perfect choice for applications requiring a highly effective and long-lasting seal. Whether you’re working with NYO-O, N2XH-J or other cable types, DuctSeal FR guarantees performance across various cable configurations. From Cable Duct Sealing to Cable Penetration Seals, it offers a comprehensive solution for ensuring fire safety across critical infrastructure.
How Fire Resistant Duct Seals Help Protect Property
Effective Fire Resistant Duct Sealing is crucial for building safety. Whether you’re dealing with commercial, industrial or residential spaces, these fire seals play a vital role in limiting the spread of flames and smoke. By sealing ducts and penetrations, you prevent fire from traveling freely through a building. This gives occupants more time to evacuate safely.
In addition to fire stopping, Fire Resistant Duct Sealing systems help protect against water and gas infiltration. This is critical in environments where both fire and flooding risks are present, such as data centres or power plants.
Conclusion: Enhance Fire Safety with the Right Duct Sealing Solutions
At the end of the day, choosing the right products is essential for ensuring long-term safety and compliance with fire safety standards. From DuctSeal FR to various fire rated sealants and fire rated foams, these materials provide reliable protection against the spread of fire, smoke and hazardous gases.
Nowadays, manufacturers test products to rigorous standards such as BS EN 1366-3:2021 and incorporate advanced technologies like Intumescent Sealants. Therefore, you can have full confidence that your Duct Sealing System will perform reliably even under the most extreme conditions.
