3M™ Scotchcast™ Resin Joint Kit LVI-0/1 (1.5 – 4mm²)
Product overview
3M™ Scotchcast™ Resin Joint Kit LVI-0/1 (1.5 – 4mm²)
The 3M LVI-0/1 Resin Joint Kit is a reliable inline jointing solution for multi-core armoured low-voltage polymeric cables. Designed for indoor, outdoor, underground and submerged installations, this 3M LVI-0/1 Kit provides proven electrical insulation and mechanical protection for LV energy cable joints. Each Scotchcast LVI-0/1 (Scotchcast LVI-01) kit includes a two-part translucent mould body with a snap-fit closing system and 3M™ Scotchcast™ 470W resin supplied in a clean, closed-mix pouch. This ensures fast, safe and consistent installation using either compression or mechanical connectors.
Part Number: 7000092614.
Key Features & Benefits
- Designed for multi-core armoured low-voltage polymeric cables (inline jointing)
- 470W Scotchcast™ resin supplied in a two-chamber closed-mix system
- Two-part translucent mould body with quick snap-fit closing system
- Stepped mould ends allow accurate trimming to suit cable diameter
- Closure cap included to prevent contamination during installation
- Suitable for indoor, outdoor, underground and submerged environments
- Provides strong electrical insulation and durable mechanical protection
- Includes Scotch™ 23 tape, armour connection parts, gloves and full instructions
- Clean, safe resin handling with disposable EN394 gloves
- Each kit is clearly marked for ease of use and traceability
3M LVI-0/1 – Reliable, Field-Proven LV Resin Jointing
The 3M Scotchcast LVI-0/1 Resin Joint is a compact, dependable alternative to traditional heat-shrink and taped joint systems. Its closed-mix 470W resin and adaptable mould design ensure consistent sealing, mechanical strength and long-term protection in demanding LV environments.
Ideal for utilities, industrial facilities, construction, infrastructure and maintenance applications, this product delivers high-quality encapsulation and reliable performance in both dry and submerged installations.
For Additional Information on the 3M™ Scotchcast™ Resin Joint Kit LVI-0/1 (1.5 – 4mm²), please consult the Technical Data Table or PDF File below.
*Technical Data subject to change without notice.
FREE Technical Advisory Service
E-Tech Components UK Ltd maintains a free technical advisory service.
Contact us for enquiries concerning this and all other products: +44 (0) 1744 762 929
Interested in this Product?
+44 (0)1744 762 929Technical Data
| CSA (mm²) | Kit Reference - 1 Core |
Kit Reference - 2 Core |
Kit Reference - 3 Core |
Kit Reference - 4 Core |
| 1.5 | - | LVI-0/1 | LVI-0/1 | LVI-0/1 |
| 2.5 | - | LVI-0/1 | LVI-0/1 | LVI-0/1 |
| 4 | - | LVI-0/1 | LVI-0/1 | LVI-0/2 |
| 6 | - | LVI-0/2 | LVI-0/2 | LVI-0/2 |
| 10 | - | LVI-0/2 | LVI-0/2 | LVI-0/2 |
| 16 | LVI-0/2 | LVI-0/2 | LVI-0/3 | LVI-0/3 |
| 25 | LVI-0/2 | LVI-0/2 | LVI-0/3 | LVI-0/4 |
| 35 | LVI-0/2 | LVI-0/3 | LVI-0/4 | LVI-0/4 |
| 50 | LVI-0/2 | LVI-0/3 | LVI-0/4 | LVI-0/4 |
| 70 | LVI-0/2 | LVI-0/4 | - | - |
| 95 | LVI-0/2 | LVI-0/4 | - | - |
| 120 | LVI-0/3 | - | - | - |
| 150 | LVI-0/3 | - | - | - |
| 185 | LVI-0/3 | - | - | - |
| 240 | LVI-0/4 | - | - | - |
| 300 | LVI-0/4 | - | - | - |
| 400 | LVI-0/4 | - | - | - |
Performance Data
Testing
Scotchcast™ Resin Kit Series LVI-0/x were tested according to EN50393 Table 3/I/A1
| Type of Test according to EN50393 Table 3 / I / A1 | Results |
| AC Voltage Withstand Test in air 4kV AC/ 1 min |
Passed |
| Insulation Resistance Test in air 1kV DC |
> 10.000MΩ |
| Heat Cycle in air 63 cycles: 5h/3h |
Passed |
| Heat Cycle in water 63 cycles: 5h/3h |
Passed |
| AC Voltage Withstand Test in water 4kV AC/ 1 min |
Passed |
| Insulation Resistance Test in water 1kV DC |
> 10.000MΩ |
