CAP-XX Prismatic Supercapacitors
Product overview
CAP-XX Prismatic Supercapacitors offer micro sized dynamic pulse power and energy harvesting. The CAP-XX Prismatic Supercapacitors range provides excellent peak power performance in a wafer-thin package. Popular Part Numbers: GZ215F, GA209F, GW201F, GS206F, HW209F
The CAP-XX Prismatic range of Supercapacitors provide a low profile, small foot print and low impedance solution to the power and performance limitations of batteries and other current-limited energy sources.
With built-in award-winning technologies, these Prismatic Supercapacitors deliver a combination of high capacitance and low equivalent series resistance (ESR). This produces very high energy density and power density, in a small, wafer-thin and lightweight package.
When used in conjunction with a low power energy source such as an energy harvester and/or low power battery, the CAP-XX Prismatic range of Supercapacitors enables extended backup time, longer battery life, and the provision of peak power as required.
CAP-XX Prismatic Supercapacitors Key Features
- Very small low profile footprint
- High pulse power capability
- Very low ESR
- Low leakage current
- Operates across a wide temperature range (-40° to +70°C)
- Meets environmental standards for disposal/operation RoHs
Typical Applications
- Energy harvesting for wireless sensors & actuators
- Peak power support to GSM/GPRS transmission
- Last gasp power for remote sensor status transmission
- Peak power support for locks and actuators
- Peak power support for portable drug delivery systems
- Short term bridging power for battery hot swaps
- Extend battery run time
Download PDF File below for Additional Information on Prismatic Supercapacitors (GZ215F, GA209F, GW201F, HW209F).
FREE Technical Advisory Service
E-Tech Components UK Ltd maintains a free technical advisory service.
Contact us for enquiries concerning this and all other products: +44 (0) 1744 762 929
Interested in this Product?
+44 (0)1744 762 929Technical Data
Dual Cell Modules (2 cells connected in series)
| Voltage | Temperature | Product Name |
CAP (±20%) |
ESR (Max=+20%) |
Body Size (mm) | Thickness (max) |
| 5.0Vnominal 5.5Vsurge |
-40°C to +70°C Tmax = 70°C |
GZ215F | 90 mF | 110 mΩ | 20.0 x 15.0 | 2.4 mm |
| 5.0Vnominal 5.5Vsurge |
-40°C to +70°C Tmax = 70°C |
GA209F | 90 mF | 95 mΩ | 20.0 x 18.0 | 2.0 mm |
| 5.0Vnominal 5.5Vsurge |
-40°C to +70°C Tmax = 70°C |
GW209F | 160 mF | 55 mΩ | 28.5 x 17.0 | 2.0 mm |
| 5.0Vnominal 5.5Vsurge |
-40°C to +70°C Tmax = 70°C |
GW201F | 400 mF | 55 mΩ | 28.5 x 17.0 | 2.5 mm |
| 5.0Vnominal 5.5Vsurge |
-40°C to +70°C Tmax = 70°C |
GW203F | 520 mF | 40 mΩ | 28.5 x 17.0 | 3.0 mm |
| 5.0Vnominal 5.5Vsurge |
-40°C to +70°C Tmax = 70°C |
GS206F | 680 mF | 30 mΩ | 39.0 x 17.0 | 2.5 mm |
| 5.0Vnominal 5.5Vsurge |
-40°C to +70°C Tmax = 70°C |
GS230F | 1200 mF | 30 mΩ | 39.0 x 17.1 | 3.5 mm |
| 5.5Vnominal 5.8Vsurge |
-40°C to +70°C Tmax = 85°C |
HW209F | 150 mF | 90 mΩ | 28.5 x 17.0 | 2.0 mm |
| 5.5Vnominal 5.8Vsurge |
-40°C to +70°C Tmax = 85°C |
HA230F | 400 mF | 120 mΩ | 20.0 x 18.0 | 3.5 mm |
| 5.5Vnominal 5.8Vsurge |
-40°C to +70°C Tmax = 85°C |
HW203F | 500 mF | 70 mΩ | 28.5 x 17.0 | 3.0 mm |
| 5.5Vnominal 5.8Vsurge |
-40°C to +70°C Tmax = 85°C |
HS206F | 650 mF | 50 mΩ | 39.0 x 17.1 | 2.5 mm |
Single Cell Devices
| Voltage | Temperature | Product Name |
CAP (±20%) |
ESR (max=±20%) |
Body Size (mm) | Thickness (max) |
| 2.75Vnominal 2.9Vsurge |
-40°C to +70°C Tmax = 85°C |
HZ102F | 170 mF | 75 mΩ | 20.0 x 15.0 | 1.2 mm |
| 2.75Vnominal 2.9Vsurge |
-40°C to +70°C Tmax = 85°C |
HA102F | 240mF | 55 mΩ | 20.0 x 18.0 | 1.2 mm |
| 2.75Vnominal 2.9Vsurge |
-40°C to +70°C Tmax = 85°C |
HA130F | 800 mF | 60 mΩ | 20.0 x 18.2 | 1.7 mm |
| 2.75Vnominal 2.9Vsurge |
-40°C to +70°C Tmax = 85°C |
HS130F | 2400 mF | 20 mΩ | 39.0 x 17.1 | 1.7 mm |
| 2.75Vnominal 2.9Vsurge |
-40°C to +70°C Tmax = 85°C |
HA114T | 120 mF | 110 mΩ | 19.5 x 20.0 | 0.7 mm |
Thinline products range in thickness from 0.6 mm to 0.7 mm.
A single or dual cell version of every part can be manufactured for high volumes, CAP-XX’s flexible production technology can tailor a part to match your needs.
